3-in-1 Sonar Bundle (2D, Down, and Side Imaging Courses + Settings Guide PDF)

All courses are viewed directly on the site on the Course Home page.

You can log in two ways:

• With your email (you’ll get a one-time password)
• Or with your Shop Pay credentials if you used Shop Pay at checkout

Courses and settings guides will be viewed/downloaded on the Course Home page.

No, once you purchase a course, you have lifetime access.

Yes! The courses are designed with beginners in mind. It walks you through everything you need to confidently use your electronics.

You’ll get it in three ways:

1. On the Course Home page after checkout
2. In a follow-up email
3. From your Orders page when you log in

If you download it to your iPhone, it will show up in the "Files" app.

They are downloadable PDFs that show you exactly how to set up your fishfinder for the clearest, most effective sonar image possible, tailored for your specific brand and model.

Yes, as long as you use the same email you checked out with, your files will always be available in your account.

Absolutely. You can print the PDF at home for quick reference on the boat.

No, if you purchase the manual, you’ll already get the settings guide as part of it.
If you just want the settings section and not all the extra content, you can purchase the settings guide by itself.

When you download a file on an iPhone, it usually saves to your Files app, not your Photos or Safari.

Here’s how to find it:

1. Open the Files app
2. Tap “Browse” at the bottom
3. Go to “Downloads” or tap “Recents”
4. Your PDF should be there and can be opened, saved, or shared from that location

Tip: You can also use the search bar in the Files app to look for the name of the file (e.g., “Humminbird Settings Guide”).

Video courses are universal—not tied to a fishfinder brand, model, or transducer. They teach how to read and use each sonar type, and the same interpretation principles apply across brands. The courses cover general settings and what those settings change, but they do not provide exact transducer-specific settings.

PDF Settings Guides are matched to the transducer installed on your boat. They provide the exact settings or recommended ranges for that specific transducer.

We recommend the relevant bundle because it gives you both: the universal video course for reading and using sonar, and the transducer-specific PDF Settings Guide for exact settings.

Check out our bundles here for total mastery at a reduced price.

Our settings guides are compatible with the following units:

ECHOMAP Units

✔ ECHOMAP UHD2 sv Models

(6" sv, 7" sv, 9" sv)

✔ ECHOMAP Ultra Series

• ECHOMAP Ultra 102sv
• ECHOMAP Ultra 106sv
• ECHOMAP Ultra 122sv
• ECHOMAP Ultra 126sv

✔ ECHOMAP Ultra 2 Series

• Ultra 2 10-inch
• Ultra 2 12-inch
• Ultra 2 16-inch

GPSMAP Units

✔ GPSMAP 7x3 / 9x3 / 12x3 / 16x3 xsv models

Examples include:

• GPSMAP 743xsv
• GPSMAP 943xsv
• GPSMAP 1243xsv
• GPSMAP 1643xsv

✔ GPSMAP 8600xsv Series

• GPSMAP 8610xsv
• GPSMAP 8612xsv
• GPSMAP 8616xsv
  (and all other 8600 xsv variants)

✔ GPSMAP 9000xsv Series

• GPSMAP 9010xsv
• GPSMAP 9013xsv
• GPSMAP 9017xsv
• GPSMAP 9022xsv
• GPSMAP 9024xsv
• GPSMAP 9027xsv
  (and other 9000 xsv models)

❌ Not Compatible

These transducers will not work with:

• Any ECHOMAP cv unit
• Any Garmin Striker unit
• Any chartplotter without a 12-pin SideVü/ClearVü port

The MEGA Imaging transducer comes standard with the Helix, Solix, and Apex units.

The Xplore units come standard with the Compact MEGA Imaging transducer.

This guide is for Humminbird XPLORE units using Compact MEGA Imaging.

This guide is for the shared Active Imaging 3-in-1 transducer. It supports Lowrance HDS Live, HDS Carbon, Elite Ti2, Elite FS, HDS Pro, and HDS Gen 3 systems using that transducer, plus compatible Simrad GO XSE, NSX, NSS evo3, and NSS evo3S systems. Match the installed transducer and sonar connection rather than assuming compatibility from the display brand alone.

Lowrance HDS Pro supports Active Imaging HD directly; supported HDS Live, HDS Carbon, and Elite FS systems use an S3100 sonar module. A sonar-equipped Simrad NSS 4 can connect directly. Supported Simrad NSX, NSS, and NSO systems may require an S3100 or S3100H. Verify the installed transducer and sonar source rather than assuming universal Simrad compatibility.
