Lowrance Eagle Eye Live Sonar PDF Settings Guide

This guide is for the Eagle Eye 9 and its dedicated Eagle Eye transducer. Eagle Eye combines focused Forward and Down live sonar with CHIRP and DownScan in one transducer and uses the Eagle twist-lock connector system. It is not the standard Eagle 9, TripleShot HD, Active Target, or Active Target 2 path.

The current Lowrance Eagle Eye Live Sonar PDF Settings Guide covers the following sections from the PDF:

• Starting Out: Definitions, Mounts, Orientation, Software Updates, Adding Eagle Eye to Home Screen
• Installation Settings: Depth Offset, Angle Offset
• Settings: Forward Range, Down Range, Contrast, Noise Reject, StableView, Range Grid, 2D Sonar, Downscan
• My Settings: Forward, Down, 2D Sonar, DownScan

It is not only a list of numbers. The PDF gives recommended settings or ranges for the exact transducer and explains the covered controls, setup, and screenshots that go with those recommendations.

This PDF is focused on setting up the exact transducer named on the product page. It includes screenshots and setup explanations, but the video courses are the step-by-step products for learning to read and use each sonar type.

Use the recommended settings as your normal baseline. The guide also explains the controls that change with what you are viewing, such as range or aim, and when to return to the normal setup. The recommendations are not split into different settings for different water clarity.

YouTube can be useful for individual questions. This guide puts the recommendations, explanations, screenshots, and setup information for one exact transducer into one ordered PDF, so you do not have to combine advice made for different equipment.

ChatGPT can help explain settings and answer questions. Check that its advice matches your exact fish finder and transducer. This PDF brings the recommended settings, explanations, and screenshots for the listed equipment together in one guide.

After checkout, the current store process makes the PDF available on the Course Home page, in a follow-up email, and from the Orders page when you log in with the same email used at checkout.

Yes. You can save the PDF to your phone or computer and print it at home. On an iPhone, downloaded PDFs normally appear in the Files app under Downloads or Recents.

The PDF Settings Guide is digital and a printed guide is not mailed. A Laminated Quick Reference Card is included only when the purchase option you select explicitly says it includes one.
